Name: NETGEAR ProSAFE XS712Tv2 12-Port 10GBase-T Gigabit Smart Managed Switch
Brand: Kaira India
SKU: XS712T-200AJS
Availability: InStock

NETGEAR ProSAFE XS712T 12-Port 10GBase-T Gigabit Smart Managed Switch

Rated for use in India
Local Service Center
Delivery options available

Industry's first 10G Smart Managed Switch, purposely design for SMB with 10G speed and easy management at an affordable cost. As a leading provider of network equipment for SMBs, NETGEAR understands the importance of a reliable and high performance network to the SMB customers. With the growth of virtualization, cloud-based services and applications like VoIP, video streaming and IP surveillance in the SMB space, SMB networks' needs extend beyond simple reliability to higher speed and performance. NETGEAR's cost-effective 10G Smart Managed Switch (XS712T) present the right solution for this requirement, delivering unprecedented 10-Gigabit bandwidth at an affordable cost. The XS712T from NETGEAR is a powerful smart managed switch that comes with 12 10-Gigabit ports and 2 Combo SFP+ for 10G Fiber links. It is designed as cost-effective 10G connections to 10G-capable servers and storages. It can also be used as a 10G access switch, connecting to a 10G managed switch (XSM7224) on one end and extend the 10G connections to the edge. The XS712T provides comprehensive L2 features in order to meet our customers' current and future needs on virtualization, converged network and mobility.

More from 10-Gigabit Switching

NETGEAR ProSAFE XS712Tv2 12-Port 10GBase-T Gigabit Smart Managed Switch

NETGEAR XS505M 5-Port 10G Multi-Gigabit Ethernet Unmanaged Switch

NETGEAR GS728TX 28-Port Gigabit/10G Stackable Smart Switch - 24 x 1G, Managed, with 2 x 10G Copper and 2 x 10G SFP+, Desktop or Rackmount, and Limited Lifetime Protection

NETGEAR GS728TX 28-Port Gigabit Stackable Smart Switch with 2-Port 10G Copper and 2-Port 10G SFP+

NETGEAR GS752TX 52-Port Gigabit/10G Stackable Smart Switch - 48 x 1G, Managed, with 2 x 10G Copper and 2 x 10G SFP+, Desktop or Rackmount, and Limited Lifetime Protection

NETGEAR GS752TX 52-Port Gigabit Stackable Smart Switch with 2-Port 10G Copper and 2-Port 10G SFP+

NETGEAR AV Line M4250-16XF (XSM4216F) 16x1G/10G Fiber SFP+ Managed Switch

NETGEAR 24-Port Fully Managed Switch M4300-28G, 24x1G, 2x10GBASE-T, 2xSFP+, Stackable, ProSAFE Lifetime Protection (GSM4328S)

NETGEAR 24-Port Fully Managed Switch M4300-28G, 24x1G, 2x10GBASE-T, 2xSFP+, Stackable (GSM4328S)

Specifications Product Datasheet Installation Guide User Manual

Features

Traffic Management

Auto Negotiation of speed and duplex modes

IEEE 802.3x Flow Control

Dynamic MAC address management

IEEE 802.1Q-based VLAN

Auto Voice VLAN

Auto Video VLAN (selected models)

VLAN routing (selected models)

QoS based on WRR, strict priority, or both

Port-based and IEEE 801.2p-based QoS

TCP/UDP-based QoS

DiffServ

IPv4 and IPv6-based QoS (selected models)

DSCP Support

Rate Limiting (ingress, or egress)

Link Aggregation and LACP

Switch Management

Web browser-based management GUI

Smart Control Center Software for multi-switch management

IP Access List

IPv6 Management

Configurable Management VLAN

SNMP v1/v2c and v3

Standard MIBs (RFC1213, RFC1643, and RFC1493)

RMON group 1, 2, 3, 9

Firmware Upgrade through Smart Control Center (TFTP)

Firmware download (to switch) and upload (to server) through TFTP/HTTP

Configuration and Image Upload (to PC) through HTTP

Configuration Download (to Switch) thru TFTP/HTTP and upload (to server)Memory & FLASH log Syslog (server) System password protection

Memory & FLASH log

Syslog (server)

System password protection

Intuitive Control

Easy-to-use software GUI lets you access, secure setup, and SNMP (NMS300) management

Whisper Quiet

A maximum of 29.1 dBA even at full power and 25OC (77OF) ambient.

Secure Your Data

Defend with Access Control, DiffServ QoS policies, LACP Link Aggregation, Private VLANs, Denial of service protection.

Cloud Management

Optional remote access for configuration, management, and monitoring through the NETGEAR Insight Cloud Portals.

Specifications

Product Number

XS712Tv2

Gigabit ports

10-Gigabit copper ports

12 10GBASE-T copper

SFP ports

2 SFP+ 1000/10GBASE-X fiber ports (shared)

Buffer size

2 MB

MAC address database size

16K

VLAN (# supported)

256

Number of LAGs & number of members

8 LAGS with max 8 members in each LAG (LACP)

Number of priority queues

Access Control Lists (ACLs)

100 shared for MAC, IP and IPv6 ACLs

IPv4 Static routes

IPV6 Static routes

Power supply

Internal 100-240VAC 50-60Hz

Max power consumption (Watts)

96 W

FAN

Acoustic Noise Level @25C (dBA)

29.1 dBA

Operating Temperature

-5° to 55°C (23° to 131°F)

MTBF

276,832 hours

Electromagnetic compliance (A or B)

Class A

Physical Specification

Dimensions: 440 x 204 x 43 mm (17.3 x 8 x 1.7 in)

Weight : 2.87 kg (6.33 lb)

Warranty

Limited Lifetime Hardware Warranty
