Name: NETGEAR AV Line M4250-16XF (XSM4216F) 16x1G/10G Fiber SFP+ Managed Switch
Brand: Kaira India
SKU: XSM4216F-100EUS
Price: 199999.0 INR
Availability: InStock

NETGEAR AV Line M4250-16XF (XSM4216F) 16x1G/10G Fiber SFP+ Managed Switch

Price

Rated for use in India
Local Service Center
Delivery options available

Introducing the NETGEAR AV Line of M4250 Switches, developed and engineered for audio/video professionals with dedicated service and support. M4250 has been built from the ground up for the growing AV over IP market, combining years of networking expertise in AV with M4300 and M4500 series with best practices from leading experts in the professional AV market.

AV codecs generally use 1Gbps or 10Gbps per stream and the AV Line of M4250 targets the widespread 1Gbps codecs. PoE+, Ultra90 PoE++ and rear-facing ports ensure a clean integration in AV racks. M4250 switches come pre-configured for standard audio and video signals. When requirements are more specific, an AV user interface offers customization with port-based profiles. For audio Dante, Q-SYS and AES67 profiles are available, as well as an AVB profile requiring an AVB license sold separately.

For video the M4250 offers profiles for NVX, AMX, Q-SYS, NDI, Dante etc. as well as audio/ video/control mixed profiles. When multiple switches are used, NETGEAR IGMP PlusTM brings automation for you to just connect them together, or with M4300 and M4500 switches.

More from Netgear

NETGEAR M4300-96X (M4300-96X) Modular, 12-slot empty Managed Switch

NETGEAR GSM4230P 24x1G PoE+ 300W 2x1G and 4xSFP Managed Switch

NETGEAR SFP 1G Ethernet RJ45 Module

Netgear 48x10G/25G SFP28 and 8x100G QSFP28 Managed Switch

Netgear XSM4556 56 Ports 48x10G/25G SFP28 and 8x100G QSFP28 Managed Switch

Netgear XS512EM 12-Port 10G-Gigabit/Multi-Gigabit Ethernet Switch with 2 SFP+ Combo Ports

NETGEAR XS508M 8-Port 10G Multi-Gigabit Ethernet Unmanaged Switch

Back to Netgear

Specifications Data Sheet Installation Guide User Manual

Features

Pre-configured for out-of-the-box use

NETGEAR IGMP Plus™ enables instant multicast functionality for most AV over IP installations

Dedicated AV web-based GUI interface

Unique interface designed for the AV professional with color-coded, port-based profiles

Profiles for common audio protocols

Quickly assign profiles to ports for Dante, AES67, and AVB audio configurations. AVB Requires a separate license

Video profiles built-in

Special profiles for NVX, SVSI, Q-SYS and Dante video profiles can be easily assigned to ports as needed

Easier configuration with new AV GUI

The AV-oriented, web-based GUI permits factory or user-specified profiles to be assigned to individual ports as needed.

Use in noise-sensitive environments

Adjustable fans can be turned off if certain conditions are met. Even the default Quiet mode is quieter than most other switches

Get up and running fast with little engineering time required

Our NETGEAR IGMP Plus^{^TM}feature is set from the factory to ensure out-of-the-box functionality for most AV over IP installations.

Multiple mounting options provide ultimate flexibility

Threaded mounting holes sized to industry standards are built into the chassis for mounting behind a display or clamped to a truss.

Specifications

Product Number

XSM4216F-100EUS

Primary Port Speed

1 Gigabit

Number of Ports

16 (1G/10G Fiber SFP+)

PoE Ports / Budget

None

IGMP Support

Enhanced (NETGEAR IGMP Plus™)

Jumbo Frame Support

Yes, up to 12kb

Acoustics

Fanless or 56.7dB@25ºC

Power Consumption

System Full Load: 47.84W/163.33Btu/hr; Standby without any port connection: 19.269W/65.78Btu/hr

AVB Support

Yes. Electronic license required, activation key sent via email (AVB4216F-10000S)

Physical Specifications

Dimensions (WxDxH) : 44 x 20 x 4.32cm

Weight : 2.80Kg (6.17lb)

Product Contents

M4250-16XF (XSM4216F)

Power cord(s)

Console USB Type-C and RJ45-DB9 cables

Rack-mounting standard brackets

Longer brackets for recessed mounting

Rubber footpads for tabletop installation

Installation guide

Warranty

Limted Lifetime Warranty
